    X-ray fluorescence NEX-OL
  • Real time process control by elemental analysis
  • Measure elements Aluminum(Al) to Uranium(U)
  • From ppm levels to weight percent(wt%) concentrations
  • Robust Rigaku NEX QC+ optical kernel with SDD detector
  • Industral touch screen user interface
  • Easy empirical calibration and routine operation
  • Routine maintenance
  • X-ray fluorescence
    NEX-OL
  • Real time process control by elemental analysis
  • Measure elements Aluminum(Al) to Uranium(U)
  • From ppm levels to weight percent(wt%) concentrations
  • Robust Rigaku NEX QC+ optical kernel with SDD detector
  • Industral touch screen user interface
  • Easy empirical calibration and routine operation
  • Routine maintenance
  • Product Features 제품특징

    NEX-OL

    Real time process control by elemental analysis
    Measure elements Aluminum(Al) to Uranium(U)
    From ppm levels to weight percent(wt%) concentrations
    Robust Rigaku NEX QC+ optical kernel with SDD detector
    Industral touch screen user interface
    Easy empirical calibration and routine operation
    Routine maintenance

    Specifications 제품사양
    Specifications
    Elemental coverage - Aluminum(Al) to Uranium(U)
    - Multi-element analysis
    Analytical head - NEX QC+ optical kernel
    - Toolless removal
    - Quick disconnects for all connections
    - Toolless X-ray window
    Excitation - 50kV X-ray tube
    - 4W max power
    - 6 tube filter positions with shutter
    Detection - Silicon drift detector(SDD)
    - Thermoelectrically cooled
    Liquid flow cell - Application specific body material
    - Toolless flow cell window change
    - Leak sensor
    Communications - MODBUS over Ethernet
    - Four 4-20mA discrete outputs
    - Eight 4-20mA discrete outputs(optional)
    - General warning : dry contact
    - General alarm : dry contact
    - Leak in cabinet : dry contact
    - Process alarm : dry contact
    Available configurations - Selt-contained one box analyzer
    - Liquid flow cell
    - Control unit box plus remote analyzed head
    - Multiple remote heads
